NE18-EL
The NE18-EL Electric Loader is the first-of-its-kind industrial vehicle to be able to deliver power performance with an all-electric drive system. With a 1.8 ton rated operating load and 9-hour operation time, the NE18-EL offers the power to handle the job efficiently while staying quiet and clean for both indoor and outdoor use.
TECHNICAL SPECIFICATIONS
Rated Load
1800kg
Operating Weight
7200kg
Bucket Capacity
1.0m³
Electric Drive Motor (Rated Power)
57kW
Electric Working Motor (Rated Power)
37.7kW
Max. Dumping Height (at angle of 45°)
2450mm
Max. Dumping Distance (at angle of 45°)
850mm
Max. Travel Speed
26km/h
Steering Angle
± 32°
Overall Dimension (L x W x H)
6300 x 1920 x 3060mm
Tire
16/70-20PR
Battery Type
Lithium Battery Power
Battery Capacity
140.92Kwh
Battery Voltage
618.24V
Charging Time
0.6~5 Hours (base on charger)
Electric Consumption
10~15 Kwh
Max. Runtime
10~13 Hours
